Color Sorters are machines used on the production lines in bulk
food processing and other industries.They sort materials by their
colors or shapes, If it is found that there are unqualified
materials or impurities in the materials, the ejector will blow out
the rejects in the hopper.
Technical Parameters
| MODEL | 6SXZ-320A |
| Chutes/Channels | 5/ 320 |
| Throughput(T/H) | 7.5-15 |
| Accuracy(Percent) | ≥99.99% |
| Power(Kwh) | 3.0 |
| Power Voltage | 220V/50Hz |
| Air compressure(Mpa) | 0.6-0.8 |
| Air Consumption(L/M) | <3.0 |
| Weight(Kg) | 1000 |
| Dimension(L*W*H) | 2455*1524*1790mm |
Working Principle of Color Sorters
Raw Material are put into the machine from its feeding hopper on
the top,vibrated by vibration device and sliding along material
chute into the zone of observationin sorting chamberthrough sensor
andbackground plate.Under the effect of light source,CCD sensor
receives compound light from materials being sorted.According to
the light intensity and color changes,make the system produce
output signal and drive solenoid valve to work ,ejecting the
discolor grain to defect chamber and good materials continue to
fall into the finished goods chamber.
Why Choose JIETAI Color Sorter
1.Running Stable
Quality assurance,
long service life.
Non-invasive sorting for all-round protection of easy to damage and
break materials.
2.Minimalist User Interface
Let you far away from debugging difficult and operation complex
trouble.
3.Super Brain Identification
Intelligent sorting,accurate identification of extremely small
color difference and extremely small heterochromatic area
materials.
4.Intelligent Valve
Intelligent control of blowing frequency,It can be achieved
optimized carryover and ultra-low air consumption.
Intelligent detection of valve running status which makes the
failure and operation life of the valve under control.
5.Powerful Function
Shape selection and color selection,intelligent color sorting plans
for flexible matching.
6.After-sale Without Worry
provide free training,consulting and technical support for users;
Provide free warranty service for one year(except the wearing spare
parts)
Application Fields
Our machine can sort many kinds of rice and grains and other
materals
►Rice:white rice;black rice;parbil rice; thai rice ;brown rice etc.
► Grains:peanut, corn,sesame,oat,millet,little lentil.
►Beans:red beens,kidney beans,coffee bean,black beans,mung beans.
►Nuts:walnut kernel,apricot kernel,sunflower
seeds,almond,watermelon seed,macadamia nut.
► Seeds:watermelon seeds;sunflower seeds.
► Industries:plastic,electronic component,industrial salt,quartz sand
►Others:tea,raisins,wolfberry,pepper.
Cooperation Case
Our mahchine can be found everywhere in
Thailand,China,India,Philippines,Algeria and others more
conuntries.
Our Service
Our Service Team
Before sales services
We will help you know ahout our color sorter,meets your special
requirementaccording to actual condition.
After sales services
1.Provide free training,consulting and technical support for users;
2.Provide personalized programs to the demands of customers;
3.Upgrade software for free for a life time;
4.Provide free warranty service for one year(except the wearing
spare parts);
5.Provide 7*24 hours consultation and urgent servicce for users.
Packaging&Shipping
Our products use professionalwooden cases with PE plastic
bag..Package size will depend on each model size.
Plaese feel free to inquire if you are interested in our procducts!
